The Jazzy® Elite ES delivers a reliable blend of power, performance and style for your active lifestyle.
The in-line, front-wheel drive technology provides tight turns around corners for optimal indoor maneuverability in small spaces and large front wheels for extra absorption over obstacles.
With superb climbing capabilities combined with front anti-tip wheels for transitioning over grade changes easily, the Jazzy Elite ES handles various terrains with ease.
In-line, front-wheel drive technology
40 amp, PG GC 3 controller
Simple main frame design for easy serviceability
Comfort high-back seat with headrest
Jazzy® Armor® controller guard to protect from daily wear and tear
Basic Jazzy Armor shroud decals
Pride FDA Class II Medical Devices are designed to aid individuals with mobility impairments.
Model | Jazzy® Elite ES |
Weight Capacity | 300 lbs. |
Turning Radius1 | 24.75" |
Width1 | 22.75" |
Length1,2 | 34.75"/41" (with footplate) |
Maximum Speed3 | Up to 4 mph |
Ground Clearance1 | 1.85" at motors |
Front Wheels | 3" solid anti-tips |
Drive Wheels | 9" solid |
Rear Wheels | 6" solid casters |
Drivetrain | Two-motor, in-line, front-wheel drive |
Braking System | Regenerative and electro-mechanical |
Suspension Type | Limited |
High-Back Seat (max. size) | 20"W x 20"D |
High-Back Seat-to-Floor Range | 21.5" - 23.5" |
Standard Electronics | 40A, PG GC3 |
Battery Size (2 required) | 12 volt, U-1 |
Standard Battery Charger | 3.5A, off-board |
Per-Charge Range3,6 | Up to 15 miles |
Battery Weight5 | 25 lbs. each |
Weight of Heaviest Piece4 | 69 lbs. |
Standard Seat Weight | 50.2 lbs. (comfort, high-back) |
Standard Seat Size | 16"x16"-18"; 18"x18"-20"; 20"x18"-20" |
Medicare Code Coverage | Group 2: Standard (K0822/K0823) |
Warranty | 5-year limited warranty on frame; 13-month limited warranty on electronics; 13-month limited warranty on drive motors; 13-month limited on batteries |
Notes: 1 Due to manufacturing tolerances and continual product improvement, this specification can be subject to a variance of + or - 3 %. Dimensions listed are for power base only. Overall measurements will vary based on seating and accessory selections. 2 Without front riggings. 3 Varies with user weight, terrain, battery type, battery condition and tire pressure. 4 Does not include seat or battery weights. 5 Battery weight may vary based on manufacturer. 6 Tested in accordance with ANSI/RESNA, WC Vol. 2, Section 4 and ISO 7176-4 standards. Results derived from theoretical calculations based on battery specifications and drive system performance. Testing conducted at maximum weight capacities. This specification can be subject to a variance of +10%, -5%. |
The information contained herein is correct at the time of publication; we reserve the right to alter specifications without prior notice.
